Additive Manufacturing Lab (Towne 187, AddLab)

Located on the first floor of the Towne engineering building, the AddLab houses the mechanical engineering department's 3D printers and post-processing equipment. The lab is generally staffed by student additive manufacturing assistants who are available to consult with members of the university on their 3D printing needs. The lab is restricted to approved workers who print and process all of the parts. If your interested in having anything 3D printed, please see our 3D printing page.

The Lab Contains the Following 3D Printers:

  • ProJet6000HD SLA Printer
  • Dimension Elite FDM Printer
  • Objet30 PolyJet Printer
  • Form1 SLA Printer








Manufacturing and Fabrication (Towne 169, Precision Machining Laboratory)

If your project requires use of the Precision Machining Laboratory you must fill out a MACHINING WORK PERMIT!

Located within room 169 on the first floor of the Towne engineering building, our machine shop includes four manual milling machines, five manual lathes, three Prototrak hybrid mills, three CNC mills (Fadal VMC-15X, Haas MiniMill, Haas OfficeMill), one CNC lathe (Haas TL-1), and assorted other metal prototyping equipment. Access to the shop is restricted to those who complete specific training and yearly recertification, as described below.

Hours - During academic sessions, the shop is nominally open from 9:00 a.m. to 10:00 p.m. Monday through Thursday, 9:00 a.m. to 7:00 p.m. Friday, 12:00 p.m. to 6:00 p.m. on Saturday, and 12:00 p.m. to 9:00 p.m. on Sunday.


Safety and Usage Policies - To use the machine shop, you must obey the following rules at ALL TIMES. Dependent upon the severity of the infraction, violation of these policies will result in either a warning or immediate revocation of access. You must:

  • Complete the training and have your name listed in the access database
  • Only work on machinery for which you have been trained
  • Never work alone (a trained supervisor or shop staff member must be in the shop area while you are working)
  • Visitors who have not been given machine shop access are not permitted in the shop.
  • Wear safety glasses (provided) at all times while inside the fabrication area
  • Wear closed-toe shoes or boots
  • Remove jewelry
  • Wear no excessively loose clothing that could get caught in rotating machinery
  • Tie back long hair
  • Do not use your cellphone or headphones while operating machinery
  • Have a clear frame of mind (no intoxication, no excessive sleep deprivation)
  • Dispose of any chemical waste in proper containers
  • No food or drink are permitted in the shop area
  • Ask for help if you are unsure of something
  • Keep all work surfaces clean and dry
  • Clean, reset, and organize equipment after use
  • Report all broken/damaged/worn tools to a member of the lab staff
  • Complete a 5-10 minute shop job (issued at the discretion of the on-duty staff person) before leaving
  • Work to ensure the safety of yourself and others
  • Any injuries must be reported immediately via an injury incident report

Training & Access - If you have little to moderate experience in a shop environment, currently the only way for you to gain access is through successful completion of MEAM201 (MEAM150 prior to June 2011), which includes the necessary training to utilize a manual mill, manual lathe, band saw, and hybrid CNC mill in a safe and efficient manner. Upon completion you will be assigned a shop access level and entered into the shop database.

Once obtained, access is valid for the remainder of the semester in which the course was taken. To have access reinstated in a subsequent semester, you must attend an all-hands safety briefing at the beginning of each term where we will refresh safety protocol and cover any changes or modifications to the equipment or shop policies (you will receive an email announcement near the start of each term to let you know when and where this will take place).

Preparation - If your project will require use of a mill or lathe, you must complete an electronic MACHINING WORK PERMIT. Once you have completed the form, you MUST submit your fully defined engineering drawing to MEAMshop@gmail.com. This form is required for all work done in the MEAM Precision Machining Laboratory (Towne 169). All work permits will need to be approved by the shop staff, Monday thru Friday ONLY. Requests submitted after 12PM on Friday will not be approved until Monday. The approval spreadsheet will reflect when your job has been approved.

Working in the Shop - Upon entry to Towne 169, you will present your PennCard to the on-duty staff person, who will sign you in and confirm your access level (note that we will keep your PennCard while you are in the shop). If you are there to work on a permitted project, your permit will be retrieved, and you will be responsible for logging machine usage.

When you complete work on a particular machine, you will need to thoroughly clean up the space, and present your permit usage log for inspection and approval by the shop staff person or on-duty student worker.

Before you leave the shop, you be assigned a brief shop job after which your PennCard will be returned.





Mechatronics (Towne 193, GM Lab)

Located on the first floor of the Towne engineering building, the GM Lab includes 18 workstations with mechatronic development tools (PCs, power supplies, oscilloscopes, and function generators), as well as soldering equipment, the MEAM ministore (assorted electronic components and mechanical fasteners), and access to the department tool crib. The lab also includes a light-duty fabrication area with a drill press, band saw, sander, assorted hand tools, and workbench space for construction and assembly. 24-hour access to the main lab is provided to students in those courses that require access to the mechatronic and/or fabrication equipment. Individuals can also request access here.

Mechatronics Tools - The lab stations include Tektronix oscilloscopes (Model TDS2002B) and Topward power supplies (model 6306A or 3303A). We also have 10 Weller WES51 soldering stations with ST7 conical tips for precision soldering of custom circuit boards.

MEAM ministore - The bins on the north wall of the lab contain a selection of electronic components (resistors, capacitors, LEDs, switches, ICs, etc.) and mechanical fasteners (both ANSI and Metric). These supplies are provided for student use in class projects. If you wish to use components for a external project, please pay for the items by depositing cash into the payment box (you will find the prices listed on the individual bins).

Tool Crib - An assortment of mechanical and electrical prototyping tools can be checked out from the window within the GM lab. Please see here for the list of available tools. An up-to-date calendar of open hours can be found on the toolcrib window.







Student Projects (Towne B11)

Located on the lower floor of the Towne engineering building, B11 is a 1600-square-foot space dedicated to student projects throughout our curriculum. This lab contains light fabrication equipment, including a 16" metal-cutting band saw, a 17 wood band saw, a variable-speed drill press, a belt and disk sander, a sheet-metal brake, and a sheet-metal shear. Many open benches are available for layout and assembly, and a small scrap area is available for the reuse and recycling of project materials. The lab also contains dedicated areas for composite-layup work and welding, though special training and certification is required to use either of these areas.

Hours - B11 is nominally open during the same hours as the Manufacturing and Fabrication lab (currently from 9:00 a.m. to 10:00 p.m. Monday through Thursday, 9:00 a.m. to 7:00 p.m. Friday, 12:00 p.m. to 6:00 p.m. on Saturday, and 11:00 a.m. to 8:00 p.m. on Sunday). You will need to use your PennCard to gain access to the lab.


Basic Access - To gain basic access to B11, you must have have a faculty-approved need for the lab and its resources. Send an email to the MEAM Coordinator of Instructional Laboratories (Meam Labs, meam-labs@lists.seas.upenn.edu ) with the title B11-Basic-Access-Request briefly explaining your need for B11 access, CC'ing the appropriate faculty member that is supporting your request (this could be a senior design advisor, research advisor, or course instructor). Also include your PennCard number (the eight bold digits), the edition (two digits to the right of the PennCard number, and expiration date of you PennCard. Upon approval, this will provide basic access to B11 for the remainder of the academic year. Basic access will allow you to swipe into B11 using your PennCard.

Basic Access entitles you to use of our work-spaces, complete with large work tables, hand tools, and measuring equipment. You will NOT have access to any of the powered machinery that resides on the west side of the room. This type of access is best suited to layout and assembly work. Note that you must adhere to all rules listed below, particularly the attire and buddy-system requirements.


Advanced Access - To gain access to the powered machinery on the west side of the room, you will need to complete the safety and machine-usage training program. This training program will familiarize you with the safety and usage procedures for our machines. This process helps ensure that you will be able to get the most out of these machines while staying safe. In order to sign up for a training session, use this Doodle signup poll. We offer training sessions each week, so please check back often. If you truly cannot make any of the sessions, contact meam-labs@lists.seas.upenn.edu to make arrangements for training.

Upon approval, you will only be able to use the machines while a B11 Lab Assistant is present to supervise you. Outside of these hours, the machines will be locked and inoperable. Please see the calendar below for our detailed supervision schedule. You will need an approved B11 Work Permit, and will surrender your PennCard to the B11 Lab Assistant while using the machines. When you are done, you will need to clean up anything that you worked on and then complete a short shop job to aid in the upkeep of B11.


Preparation] - If your project will require use of any of the machinery, you must complete page one of a [B11 Work Permit (including an engineering drawing or detailed sketch!) and have it signed by a full-time staff member. Once approved, your will be free to begin work on your project during supervised hours.


Safety and Usage Policies - To use the project space, you must obey the following rules at ALL TIMES. Dependent upon the severity of the infraction, violation of our policies will result in either a warning or immediate revocation of access. You must:

  • Receive basic access approval prior to entering the room
  • Receive advanced access approval prior to using any machinery
  • Never work alone
  • Wear safety glasses (provided) at all times while inside the fabrication area
  • Wear closed-toe shoes or boots
  • Remove jewelry
  • Wear no excessively loose clothing that could get caught in rotating machinery
  • Tie back long hair
  • Do not use your cellphone or headphones while operating machinery
  • Have a clear frame of mind (no intoxication, no excessive sleep deprivation)
  • Dispose of any chemical waste in proper containers
  • No food or drink are permitted in the fab area
  • Ask for help if you are unsure of something (if staff are not present in B11, inquire in the main shop)
  • Keep all work surfaces clean and dry
  • Clean, reset, and organize equipment after use
  • Report all broken/damaged/worn tools to a member of the lab staff
  • Any injuries must be reported immediately via an injury incident report
  • Anything left out on the benches without an authorization tag will be considered trash


Project Authorization Tags - During closing each evening, the benchtops in the lab will be wiped down, and anything left out will be considered trash. If your project requires that you maintain a benchtop space for a period of time, you must send an email request to meam-labs@lists.seas.upenn.edu with the title B11-Project-Tag with the following content in the body of the email: 1. your name, 2. the course and/or project, 3. the start date (when you need to start leaving your project out), 4. the end date (when you anticipate being able to remove your project), 5. justification (explanation of why you can't store this somewhere else). This email must be sent at least two days before the requested start date.






Rapid Prototyping (Laser Cutting, 3D Printing)

Located within room 167 on the first floor of the Towne engineering building, the Laser Shop contains two Universal Laser X-660 laser systems that provide students with the ability to cut various nonmetallic materials. Four dedicated PC workstations are available to provide CAD support for part design and fabrication on these systems. In order to use the laser cutters, students must attend a brief training session (sign-ups can be found on the door to Towne 167). 24-hour access to this room is controlled by a card reader on the door. For more information, see the Laser Cutting page.

We also have one Dimension Elite FDM printer and one Objet30 photo-resin printer that are operated in a full-service capacity. For more informatiion, see the 3D Printing page.





Design & Simulation Lab (Towne 205)

(details coming soon)





PACE Laboratory (Towne 195)

(details coming soon)





Mechanical Experimentation Laboratory (Towne M81)

(details coming soon)





Mechanical and Aerodynamic Testing (Towne B2)

(details coming soon)
